PFA KL-75 Series Alignment Screw

A metal assembly consisting of a large bolt, two washers, and a black rubber element, possibly a vibration damper, on a grey surface.
A metal assembly consisting of a large bolt, two washers, and a black rubber element, possibly a vibration damper, on a grey surface.
CAD-KL-75-AS

PFA KL-75 Series Alignment Screw

$78.75

Alignment Screw for Model 75 Series Preloading Hydraulic Locking Cylinder – PFA KOR-LOK Side-Action System. Placed in Rod end as part of the loose coupling system. Has rounded face to keep forces centered and works with PFA mating part alignment coupler (AC) to accommodate misalignments.

IN STOCK

SKU: KL-75-AS
Categories: ,

Item Details

Weight 0.07 lbs
Dimensions 2 × 1 × 1 in

CAD File

PFA provides FREE APPLICATION REVIEW SUPPORT and parametric 3D CAD models in partnership with CADENAS Part Solutions. Please click on the button below to open up the CAD file for this product in a new window. Please make sure you have your popup blocker disabled.

View KL-75-AS CAD File
